Cast from corten steel, usually in India or China and weighing 2.5 kg (23lb) they are the structural elements that are used to lift shipping containers as well as to connect them to whichever mode of transportation is being used to move the.

#Iso 1161 corner blocks drawings iso#

containers which conform to ISO 668 and ISO 1496 (all parts) with the exception of air mode containers (see ISO 8323).

#Iso 1161 corner blocks drawings series#

Shipping container structural drawings, CAD drawings, fabrication drawings and engineering drawings are essentially the same. What is a corner casting ISO1161 corner castings are the big three-holed blocks of corten steel which form the corners of all ISO shipping containers. This International Standard establishes the basic dimensions and the functional and strength requirements of corner and intermediate fittings for series 1 freight containers, i.e. What types of Shipping Container Technical Drawings are available? The drawing will also show both the tare and gross weight capacity together with a reference number and the name of the person or company who designed and authorized the drawing. Door opening widths, heights, gauge thickness of the steel, the position of components such as lashing points, the types of materials used, such as Corten steel and galvanized locking components. Internal and external width measurements and dimensions are a key part of shipping container technical drawings. What is included in a Shipping Container Technical Drawing?

Technical drawings are continually referenced during a construction project from the initial planning right through until the completion of the project. The drawings are particularly useful as a reference material when measurements are required, since the drawings are made to scale. Shipping container technical drawings are used by architects and engineers to communicate information to people on a building or construction project. BV Certified Casting Steel ISO 1161 Container Corner Blocks, US 110 - 140 / Set, 1 Year, Online technical support, graphic design.Source from Tianjin Jinbin Huaxing Mechanical Fitting Co., Ltd. What is a Shipping Container Technical Drawing used for? The drawing also shows the dimensions and position of the equipment fitting to the shipping container such as the locking rods and air vents. The drawing is made to scale and shows various angles and views such as the doors, end, sides and top of the container. What is a Shipping Container Technical Drawing?Ī shipping container technical drawing is a detailed and accurate drawing showing the exact measurements of a Conex container.

#Iso 1161 corner blocks drawings pdf#

The physical dimensions are per the sales drawings found on our website, and mirror ISO 1161 requirements.Download FREE PDF Shipping Container Drawings now from Conex Depot. (With respect to front door of container.) Updated to correct corner feature. applications used outside of the ISO 1161 corner fittings’ original design intent). Top and Bottom Left Corners, and Top and Bottom Right Corners of ISO containers (with IGES files). Armed with this information, end users can employ engineers of their choosing to determine the strength (WLL) of the corner fittings in their given custom applications (i.e.

As an ISO sanctioned design, Tandemloc may only provide customers the physical dimensions and minimum material properties of the corner fittings. Each of these will have possibly dramatic impacts on how the corner fitting will respond under a given load. TANDEMLOC'S ENGINEERING DEPARTMENT’S STATEMENT REGARDING ISO 1161 CORNER FITTING WLL:Īn ISO 1161 Corner Fitting’s WLL is dependent upon how it is held in place, how it is loaded, and the physical size (bearing area) of the components used to engage the corner fittings.
